EN Flange - Specifications
EN Flange PN 6 to PN 40 - Materials, Grades & Standards
| Pressure Rating (PN) |
Material | Grade / Standard |
Applications | Remarks |
|---|---|---|---|---|
| PN 6 | Carbon Steel | EN 10025-2, S235JR | Low-pressure pipelines, water lines |
Suitable for mild operating conditions |
| PN 6 | Stainless Steel | EN 1.4301 (304), EN 1.4404 (316L) | Chemical, food processing, low-pressure systems |
Corrosion-resistant |
| PN 10 | Carbon Steel | EN 10025-2, S275JR | Industrial, HVAC, moderate-pressure pipelines |
Standard low-pressure industrial usage |
| PN 10 | Stainless Steel | EN 1.4301 (304), EN 1.4404 (316L) | Petrochemical, chemical pipelines |
Good corrosion resistance |
| PN 16 | Carbon Steel | EN 10025-2, S355JR | Moderate-pressure industrial pipelines |
Commonly used in oil & gas, water, chemical |
| PN 16 | Stainless Steel | EN 1.4301 (304), EN 1.4404 (316L) | Petrochemical, chemical, power plants |
Corrosion and temperature-resistant |
| PN 25 | Carbon Steel | EN 10222-2, P265GH | High-pressure oil & gas pipelines |
Suitable for higher stress and pressure |
| PN 25 | Stainless Steel | EN 1.4404 (316L) | Chemical and high-pressure applications |
Excellent corrosion and temperature performance |
| PN 40 | Carbon Steel | EN 10222-2, P355GH | High-pressure pipelines in oil, gas, power |
Heavy-duty industrial applications |
| PN 40 | Alloy Steel | EN 10222-5, 13CrMo44 | High-pressure, high-temperature environments |
Heat and pressure resistant |
EN Standard Flanges – Dimensions
| DN / NB | PN | Flange Type | Outside Diameter (OD, mm) | Thickness / Face-to-Face (mm) | Bolt Circle Diameter (BCD, mm) | No. of Bolt Holes | Bolt Hole Diameter (mm) | Raised / Flat Face Height (mm) |
|---|---|---|---|---|---|---|---|---|
| 15 (1/2″) | PN 6-40 | WN | 95 | 14-24 | 65-95 | 4 | 14 | 2-3 |
| 15 (1/2″) | PN 6-40 | SO | 95 | 10-20 | 65-95 | 4 | 14 | 2-3 |
| 15 (1/2″) | PN 6-40 | BL | 95 | 12-22 | 65-95 | 4 | 14 | 2-3 |
| 15 (1/2″) | PN 6-40 | TH | 95 | 12-22 | 65-95 | 4 | 14 | 2-3 |
| 15 (1/2″) | PN 6-40 | LJ | 95 | 10-20 | 65-95 | 4 | 14 | 2-3 |
| 50 (2″) | PN 6-40 | WN | 165 | 18-28 | 125-145 | 8 | 18 | 2-3 |
| 50 (2″) | PN 6-40 | SO | 165 | 16-26 | 125-145 | 8 | 18 | 2-3 |
| 50 (2″) | PN 6-40 | BL | 165 | 20-30 | 125-145 | 8 | 18 | 2-3 |
| 50 (2″) | PN 6-40 | TH | 165 | 18-28 | 125-145 | 8 | 18 | 2-3 |
| 50 (2″) | PN 6-40 | LJ | 165 | 16-26 | 125-145 | 8 | 18 | 2-3 |
| 100 (4″) | PN 6-40 | WN | 220 | 22-36 | 180-200 | 8 | 18-20 | 2-3 |
| 100 (4″) | PN 6-40 | SO | 220 | 20-34 | 180-200 | 8 | 18-20 | 2-3 |
| 100 (4″) | PN 6-40 | BL | 220 | 28-40 | 180-200 | 8 | 18-20 | 2-3 |
| 100 (4″) | PN 6-40 | TH | 220 | 24-38 | 180-200 | 8 | 18-20 | 2-3 |
| 100 (4″) | PN 6-40 | LJ | 220 | 22-36 | 180-200 | 8 | 18-20 | 2-3 |
| 1200 (48″) | PN 6-40 | WN | 2200 | 80-120 | 2100-2150 | 48 | 36 | 5-10 |
| 1200 (48″) | PN 6-40 | SO | 2200 | 70-110 | 2100-2150 | 48 | 36 | 5-10 |
| 1200 (48″) | PN 6-40 | BL | 2200 | 100-140 | 2100-2150 | 48 | 36 | 5-10 |
| 1200 (48″) | PN 6-40 | TH | 2200 | 90-130 | 2100-2150 | 48 | 36 | 5-10 |
| 1200 (48″) | PN 6-40 | LJ | 2200 | 80-120 | 2100-2150 | 48 | 36 | 5-10 |
EN Forged Flanges - Weight Chart
| DN / NB | Flange Type | PN | Weight (kg) |
|---|---|---|---|
| 15 (1/2″) | WN | 6-40 | 1.5 – 2.5 |
| 15 (1/2″) | SO | 6-40 | 1.2 – 2.0 |
| 15 (1/2″) | BL | 6-40 | 1.8 – 2.8 |
| 15 (1/2″) | TH | 6-40 | 1.6 – 2.5 |
| 15 (1/2″) | LJ | 6-40 | 1.2 – 2.0 |
| 50 (2″) | WN | 6-40 | 5 – 8 |
| 50 (2″) | SO | 6-40 | 4 – 7 |
| 50 (2″) | BL | 6-40 | 6 – 9 |
| 50 (2″) | TH | 6-40 | 5 – 8 |
| 50 (2″) | LJ | 6-40 | 4 – 7 |
| 100 (4″) | WN | 6-40 | 15 – 25 |
| 100 (4″) | SO | 6-40 | 12 – 20 |
| 100 (4″) | BL | 6-40 | 18 – 28 |
| 100 (4″) | TH | 6-40 | 16 – 26 |
| 100 (4″) | LJ | 6-40 | 12 – 20 |
| 300 (12″) | WN | 6-40 | 120 – 180 |
| 300 (12″) | SO | 6-40 | 90 – 150 |
| 300 (12″) | BL | 6-40 | 150 – 220 |
| 300 (12″) | TH | 6-40 | 130 – 200 |
| 300 (12″) | LJ | 6-40 | 90 – 150 |
| 600 (24″) | WN | 6-40 | 500 – 750 |
| 600 (24″) | SO | 6-40 | 400 – 700 |
| 600 (24″) | BL | 6-40 | 600 – 900 |
| 600 (24″) | TH | 6-40 | 500 – 800 |
| 600 (24″) | LJ | 6-40 | 400 – 700 |
| 1200 (48″) | WN | 6-40 | 2800 – 4000 |
| 1200 (48″) | SO | 6-40 | 2500 – 3800 |
| 1200 (48″) | BL | 6-40 | 3000 – 4200 |
| 1200 (48″) | TH | 6-40 | 2800 – 4000 |
| 1200 (48″) | LJ | 6-40 | 2500 – 3800 |
EN Piping Flanges - Tolerances
| Parameter | Tolerance / Limit | Remarks |
|---|---|---|
| Outside Diameter (OD) | ± 1% of nominal diameter | Ensures proper alignment with mating flanges |
| Bolt Circle Diameter (BCD) | ± 1% | Maintains uniform bolt fitment and stress distribution |
| Number of Bolt Holes | ± 0 (Exact) | EN standard requires precise hole count |
| Bolt Hole Diameter | ± 0.5 mm | To allow correct bolt insertion without play |
| Flange Thickness / Face-to-Face | +12.5% / -0% | Ensures minimum wall thickness for pressure rating |
| Raised Face (RF) Height | ± 1 mm | Provides proper gasket seating for leak-proof sealing |
| Flatness (Flange Face) | ≤ 0.5 mm | Critical for leak-tight joint in high-pressure systems |
| Out-of-Roundness | ≤ 1.5% of nominal OD | Prevents misalignment during installation |
| Concentricity / Centering | ≤ 1% of nominal OD | Maintains proper pipe alignment and stress distribution |
| Machining Surface Finish | Ra 3.2 μm (typical) | Ensures gasket sealing and smooth contact surface |
| Angular Tolerance (for Weld Neck) | ≤ 1° | Ensures correct alignment with welded pipes |
What are the different types of EN Flanges (with Type Numbers)?
EN Flanges are categorized under EN 1092-1 standard types, each serving a specific piping purpose:
- Type 05 – Blind Flange (BL):
- Used to close pipeline ends, pressure test, or isolate sections.
- Type 11 – Weld Neck Flange (WN):
- Designed for butt-welded connections, ideal for high-pressure and high-temperature applications.
- Type 12 – Long Weld Neck Flange:
- Extended neck provides additional stress distribution in pipelines.
- Type 13 – Threaded Flange (TH):
- Can be screwed onto pipes without welding, suitable for low-pressure systems.
- Type 21 – Slip-On Flange (SO):
- Pipes slip into the flange, easy to install and suitable for moderate pressures.
- Type 22 – Lap Joint Flange (LJ):
- Works with stub ends, ideal for systems that require frequent dismantling or maintenance.
- Type 23 / 24 – Reducing Flanges / Special Flanges:
- Custom flanges for connecting different pipe sizes or high-performance applications.
Key Points:
- Flanges are available in Carbon Steel, Stainless Steel, and Alloy Steel.
- Each type has specific dimensional, bolt, and pressure specifications as per EN 1092-1.
- Choosing the correct flange type ensures system integrity, leak-proof sealing, and operational safety.
What are the pressure ratings of EN Flanges?
EN Flanges are designed for PN 6 to PN 40 pressure classes, covering low to high-pressure systems:
- PN 6: Low-pressure pipelines, water supply, and general industrial applications.
- PN 10: Moderate-pressure chemical and HVAC systems.
- PN 16: Common for moderate to high-pressure pipelines in petrochemical and industrial applications.
- PN 25: High-pressure pipelines in oil & gas, chemical, and power plants.
- PN 40: Heavy-duty applications in high-pressure, high-temperature industrial systems.
What are the main advantages of using EN Flanges?
- Standardized dimensions for interchangeability.
- Wide variety of types for all industrial needs (WN, SO, BL, TH, LJ).
- High-pressure and temperature resistance suitable for PN 6–PN 40.
- Compatibility with Carbon Steel, Stainless Steel, and Alloy Steel pipelines.
- Leak-proof connections due to precise tolerances and surface finishes.
- Suitable for critical industrial applications: oil & gas, chemical, petrochemical, power plants.
